Product Description
Key Features: * All models with Dual combustion room. * Stainless Steel chimney/stack, long life. *based on order * High fever, long life of incinerator. * Free or minimal installation onsite. * High speed, from 10kgs to 500kgs per hour, up to 6ton per day. * PLC Control Plane. *based on order New Design for pet animal cremation business. * One year guarantee on incinerator and parts in stock.
Nanjing Clover Medical Technology Co., Ltd.. Is a leading waste incinerator maker in China. We are local manufacturer and one of the greatest exporter of China. Pyrolytic incinerator equipment technical is primary waste treatment all of the planet, for Medical Waste, Animal Incineration, Pet cremation and other good wste. The potential from 10kgs/Hr. To 500kgs/Hr. , up to 6ton per day. Currently, medical waste incinerators produces and suppliers, medical waste incinerators vs animal crematory, medical waste incinrators in china, medical waste italy, we supply different show for local consumer requirements and design upgraded incinerator with our leading technology. The upgraded design feature of our assortment of incinerators make them one of the most cost effective in the world.
| Items/Model | A1500 | A2400 | A4000 | A5500 |
| Burning Rate *animal | 90 kgs/Hr. | 150 kgs/Hr. | 200 kgs/Hr. | 400 kgs/Hr. |
| Feed Capacity *animal | 120 kgs | 200 kgs | 300 kgs | 500 kgs |
| Equipment Weight | 7000 kgs | 8300 kgs | 13000 kgs | 16500 kgs |
| Primary Chamber (Liters) | 1500 | 2400 | 4000 | 5500 |
| Secondary Chamber (Liters) | 500 | 1200 | 1500 | 1500 |
| External Dimensions (cm) | 240x170x380 | 260x220x420 | 320x220x460 | 360 x 220 x 475 |
| Internal Dimensions (cm) | 150x100x96 | 220x110x100 | 257x147x108 | 300 x 147 x 125 |
| Oil Tank(Liters) | 500 | 500 | 500 | 500 |
| Door Opening (cm) | 59 x 81 | 90 x 110 | 108 x 128 | 108 x 128 |
| Chimney (M) | 10 | 10 | 14 | 14 |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| Secondary Chamber | YES | YES | YES | YES |
| Mix-Combustion Chamber | YES | YES | YES | YES |
| Smoke Filter Chamber | YES | YES | YES | YES |
| Combustion Fuel | Oil/Gas | Oil/Gas | Oil/Gas | Oil/Gas |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Temperature Monitoring | YES | YES | YES | YES |
| 1st. Chmaber Temperature | 800degree–1000degree | 800degree–1000degree | 800degree–1000degree | 800degree–1000degree |
| 2nd. Chmaber Temperature | 800degree–1000degree | 800degree–1000degree | 800degree–1000degree | 800degree–1000degree |
