Nanjing Clover Medical Technology Co., Ltd..
Currently , we supply different series for local customer requirements and design upgraded incinerator with our leading technology. The upgraded design feature of our assortment of incinerators make them one of the most cost effective in the world.
| Items/Model | TS20(PLC) |
| Burn Rate | 20 kg/hour |
| Feed Capacity | 40kg |
| Control Mode | PLC |
| Combustion Chamber | 210L |
| Internal Dimensions | 65x65x50cm |
| Secondary Chamber | 110L |
| Smoke Filter Chamber | Yes |
| Feed Mode | Manual |
| Voltage | 220V |
| Power | 0.5Kw |
| Oil Consumption (kg/hour) | 7.8–16.3 |
| Gas Consumption (m3/hour) | 8–15.7 |
| Temperature Monitor | Yes |
| Temperature Protection | Yes |
| Oil Tank | 100L |
| Feed Door | 45x40cm |
| Chimney | 3Meter |
| Chimney Type | Stainless Steel |
| 1st. Chamber Temperature | 800–1000 degree |
| 2nd. Chamber Temperature | 1000-1200degree |
| Residency Time | 2.0 Sec. |
| Gross Weight | 2200kg |
| External Dimensions | 160x110x130cm |
Key Features: * All versions with Dual combustion room. * High fever, long life of incinerator. * Free or minimum installation onsite. * High speed, from 10kgs to 600kgs per hourto 10ton per day. * PLC Control Plane for Intelligent functioning. * New Design for pet animal cremation business. * One year warranty on incinerator and parts in stock.
