* Burning Rate (50-120kg/hour)
* Minimum Operating Temperature (850°ϲ(Primary combustion)
* Maximum Operating Temperature (1450°ϲ(Afterburner chamber)
* Secondary Burning Capacity (Compulsory)
* Density Insulation (20mm high)
* Refractory Casting (Minimum 65mm)
* Heavy duty refracting lining to withstand (1500°ϲ)
* Average burn out time: Maximum (3.0 hours)
* Fuel Type (Diesel)
* Fuel Consumption in L/hr: (7.5 to 9)
* Residence time in secondary chamber (2 sec.)
* Residue ash post 100kg (Max. 3.8kg)
* Installation period (Maximum 7days)
Type : Refractory constructions
Steel Structure 400+ Silica board + Fire Brick and
Castable between
Size : Outside – W 740 x L 1112 x H 790 / Inside – W 400 x L 800 x H 560 (mm)
Fire load of Combustion volume : 0.18 m3
Fire table area : 0.32 m2
Material : SS400 x 6.0T, Silica Board, Fire Brick (SK-36), Castable (HACT-160)
Temperature : 700 ~ 900 ℃
Residual gas combustion in secondary chambers : ≥ 2sec
Input door size : W 200 x H 200 (mm)
Ash door size : W 300 x H 400 (mm)
Type : Refractory constructions
Steel Structure 400+ Silica board + Fire Brick and Castable between
Size : Outside – W 740 x L 1112 x H 745 / Inside – W 400 x L 800 x H 600 (mm)
Fire load of Combustion volume : 0.19 m3
Fire table area : 0.32 m2
Material : SS400 x 6.0T, Silica Board 50T, Fire Brick (SK-36), Castable (HACT-160)
* Minimum Operating Temperature (850°ϲ(Primary combustion)
* Maximum Operating Temperature (1450°ϲ(Afterburner chamber)
* Secondary Burning Capacity (Compulsory)
* Density Insulation (20mm high)
* Refractory Casting (Minimum 65mm)
* Heavy duty refracting lining to withstand (1500°ϲ)
* Average burn out time: Maximum (3.0 hours)
* Fuel Type (Diesel)
* Fuel Consumption in L/hr: (7.5 to 9)
* Residence time in secondary chamber (2 sec.)
* Residue ash post 100kg (Max. 3.8kg)
* Installation period (Maximum 7days)
Type : Refractory constructions
Steel Structure 400+ Silica board + Fire Brick and
Castable between
Size : Outside – W 740 x L 1112 x H 790 / Inside – W 400 x L 800 x H 560 (mm)
Fire load of Combustion volume : 0.18 m3
Fire table area : 0.32 m2
Material : SS400 x 6.0T, Silica Board, Fire Brick (SK-36), Castable (HACT-160)
Temperature : 700 ~ 900 ℃
Residual gas combustion in secondary chambers : ≥ 2sec
Input door size : W 200 x H 200 (mm)
Ash door size : W 300 x H 400 (mm)
Type : Refractory constructions
Steel Structure 400+ Silica board + Fire Brick and Castable between
Size : Outside – W 740 x L 1112 x H 745 / Inside – W 400 x L 800 x H 600 (mm)
Fire load of Combustion volume : 0.19 m3
Fire table area : 0.32 m2
Material : SS400 x 6.0T, Silica Board 50T, Fire Brick (SK-36), Castable (HACT-160)
Temperature : 1000 ~ 1100 ℃
Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: sales@hiclover.com
Email: hicloversales@gmail.com
Website: www.hiclover.com
Email: sales@hiclover.com
Email: hicloversales@gmail.com
| Items/Model | TS10(PLC) | TS20(PLC) | TS30(PLC) | TS50(PLC) | TS100(PLC) |
| Burn Rate (Average) | 10 kg/hour | 20 kg/hour | 30 kg/hour | 50 kg/hour | 100 kg/hour |
| Feed Capacity(Average) | 20kg | 40kg | 60kg | 100kg | 200 kg |
| Control Mode | PLC | PLC | PLC | PLC | PLC |
| Combustion Chamber | 100L | 210L | 330L | 560L | 1200L |
| Internal Dimensions | 50x50x40cm | 65x65x50cm | 75x75x60cm | 100x80x70cm | 120x100x100cm |
| Secondary Chamber | 50L | 110L | 180L | 280L | 600L |
| Smoke Filter Chamber | Yes | Yes | Yes | Yes | Yes |
| Feed Mode | Manual | Manual | Manual | Manual | Manual |
| Voltage | 220V | 220V | 220V | 220V | 220V |
| Power | 0.5Kw | 0.5Kw | 0.5Kw | 0.7Kw | 0.7Kw |
| Oil Consumption (kg/hour) | 5.4–12.6 | 7.8–16.3 | 10.2–20 | 12.1–24 | 14–28 |
| Gas Consumption (m3/hour) | 6.2–11.4 | 8–15.7 | 9.8–20 | 9.9–26.1 | 10–32.2 |
| Temperature Monitor | Yes | Yes | Yes | Yes | Yes |
| Temperature Protection | Yes | Yes | Yes | Yes | Yes |
| Oil Tank | 100L | 100L | 100L | 100L | 200L |
| Feed Door | 30x30cm | 45x40cm | 55x50cm | 70x55cm | 80x60cm |
| Chimney | 3Meter | 3Meter | 5Meter | 5Meter | 10Meter |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| 1st. Chamber Temperature | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ | 800℃–1000℃ |
| 2nd. Chamber Temperature | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ | 1000℃-1200℃ |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Gross Weight | 1500kg | 2200kg | 3000kg | 4500kg | 6000kg |
| External Dimensions | 140x90x120cm | 160x110x130cm | 175x120x140cm | 230x130x155cm | 260x150x180cm |
